For Mellanox MMA1T00-VS Compatible 200GBASE-SR4 QSFP56 850nm 100m Transceiver
US$ 289.00 (Excl. VAT)
OPTCORE replacement for Mellanox 200G QSFP56 SR4 transceiver, works flawlessly in Mellanox 200G Ethernet switches, routers, servers and NICs.
OPTCORE for Mellanox MMA1T00-VS Compatible 200GBASE-SR4 QSFP56 Transceiver (MMF, 850nm, 100m, MPO/MTP, DOM)
Buy a reliable 200GBASE-SR4 QSFP56 optical transceiver replacement compatible with your Mellanox MMA1T00-VS at OPTCORE! We provide a third-party 200G QSFP56 SR4 transceiver replacement, the perfect way to ensure your switch platform works properly while saving money. This QSFP56 module supports 200Gbps speed for a 100m link distance via OM4 or 70m via OM3 with FEC.
Features
• OPTCORE replacement for Mellanox MMA1T00-VS 200GBASE-SR4 QSFP56 transceiver
• QSFP56 MSA-compliant
• 4×53Gbps electrical interface (200GAUI-4)
• Metal enclosure for lower EMI
• Built-in digital diagnostic functions for real-time monitor
• RoHS compliant and lead-free
Proven Performance
When performance and reliability are vital, use our high-quality optics to build your network. OPTCORE optics are engineered, produced, and tested in the factory for reliable end-to-end quality.
Proven Compatibility
There’s an easy way to verify compatibility: test in real network devices. OPTCORE optics are tested in multi switch devices for compatibility to ensure flawless functioning.
Enjoy Massive Saving
Compared to the original optics, the OPTCORE transceiver can save you up to 80% on project and networking cabling. You won’t find a better combination of quality and affordability.
Specification
| Compatible OEM Part# | MMA1T00-VS | Manufacturer | OPTCORE |
| Manufacturer Part# | QSFP56-200G-SR4 | Form Factor | QSFP56 |
| Data Rate | 200Gbps (4x 50Gbps) | Wavelength | 850 nm |
| Media Type | MMF | Max Distance | 70m@OM3, 100m@OM4 |
| Transmitter Type | VCSEL | Receiver Type | PIN |
| Transmitter Power | -4.5 ~ 3.0 dBm | Receiver Sensitivity | < -8.4 dBm |
| Extinction Ratio | > 3.0 dB | Receiver Overload | > 4.0 dBm |
| Connector | MPO/MTP-12 | Max Power Consumption | 4.5 W |
| DDM/DOM | Yes | Compliance | RoHS, CE, REACH QSFP56 MSA, SFF-8665, IEEE 802.3bs |
| Environment | Operating Temperature: 0 to 70 °C Storage Temperature: -40 to 85 °C Operating Humidity: 5%~85%, noncondensing Storage Humidity: 5%~95%, noncondensing |
Application | 200G Ethernet transmission Proprietary High-Speed Interconnections High-performance computing clusters |
| Shipping Weight | 0.07 kg | Dimensions (L x W x H) | 118.3 x 18.4 x 8.5 mm |
Compatibility
• Mellanox 200G switches
• Mellanox 200G routers
• Mellanox 200G firewalls
• Mellanox 200G fiber media converter
• Mellanox 200G network adapters
• Mellanox 200G network interface card (NICs)
Ordering Information
| Manufacturer Part Number | Description |
| QSFP56-200G-SR4 | OPTCORE for Mellanox MMA1T00-VS Compatible 200GBASE-SR4 QSFP56 Transceiver, MMF, 850nm, 100m, MPO/MTP, DOM |
Download
Note: All trademarks, products, and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is NOT certified or endorsed by Mellanox.
| Weight | 0.07 kg |
|---|
