OPTCOREnet OSP1250-8505DCR 1000BASE-SX SFP 850nm 550m Transceiver
US$ 5.00 (Excl. VAT)
- Date first listed: 05/05/2024
- OPTCOREnet 1000BASE-SX SFP module
- Compliant with SFP MSA standard and IEEE 802.3z
- Built-in Digital Optical Monitoring for real-time diagnostic
- Low power consumption < 0.8 W
- Duplex LC connector
OPTCOREnet OSP1250-8505DCR 1000BASE-SX SFP Transceiver Module (MMF, 850nm, 550m, LC, DOM)
This OPTCOREnet OSP1250-8505DCR SFP module supports 1000BASE-SX connectivity over multimode fiber cable (MMF). It supports a link distance of 550m via 50µm OM2 or 220m via 62.5µm OM1 fiber. This multimode transceiver module complies with SFP MSA, IEEE 802.3z, and SFF-8472, so it is suitable for any MSA-compliant equipment.
Specifications
| Brand | OPTCOREnet | Manufacturer | OPTCOREnet |
| Manufacturer Part# | OSP1250-8505DCR | Form Factor | SFP |
| Data Rate | 1.25 Gbps | Wavelength | 850 nm |
| Media Type | MMF | Max Distance | 1km@50/125µm OM3 550m@50/125µm OM2 [email protected]/125µm OM1 |
| Transmitter Type | VCSEL | Receiver Type | PIN |
| Transmitter Power | -9 ~ -3 dBm | Receiver Sensitivity | < -18 dBm |
| Extinction Ratio | > 9 dB | Receiver Overload | > 0 dBm |
| Connector | LC Duplex | Power Consumption | 0.8 W |
| DDM/DOM | Yes | Compliance | RoHS, CE, REACH SFP MSA, IEEE 802.3z, SFF-8472 |
| Environment | Operating Temperature: 0~70°C Storage Temperature: -40~85°C |
Application | Gigabit Ethernet 1G Fibre Channel Switch to Switch Interface Switch to NIC or Media Converter Interface Other 1G Optical Links |
| Shipping Weight | 0.03 kg | Dimensions (LxWxH) | 55.5×13.7×12 mm |
Resources
Datasheet
Note: All trademarks, products, and company names mentioned are the property of their respective owners and are used for comparative purposes only.
