Cisco ONS-SI-155-L2 Compatible OC-3/STM-1 LR-2 SFP Industrial Transceiver
US$ 32.00 (Excl. VAT)
155Mbps OC-3/STM-1 LR-2 SFP module (SMF, 1550nm, 80km, LC, DDM, Ind Temp.) for use with Cisco ONS platforms.
Similar Products
ONS-SI-155-I1 ONS-SI-155-L1 ONS-SE-100-LX10 ONS-SI-100-LX10 ONS-SI-100-FX ONS-SE-100-BX10U ONS-SE-100-BX10D
Cisco ONS-SI-155-L2 Compatible OC-3/STM-1 LR-2 SFP Module (SMF, 1550nm, 80km, LC, DDM, Ind Temp.)
This OC-3/STM-1 LR-2 SFP module is suitable for long reach connecting with Cisco equipment and equivalent to genuine part number ONS-SI-155-L2. It supports maximum transmission distance of 80km with 155Mbps data rate over single mode fiber. It is programmed and tested at the factory, to ensure works with Cisco ONS Multiservice Transport Platform. It is manufactured with high-quality components and optimized to meet or exceed the specifications of the OEM, while with lower pricing to help the clients reduce the cost of network infrastructure.
Features
• Functionally identical to Cisco ONS-SI-155-L2
• Up to 80km on 9/125µm single mode fiber
• Compliant with IEEE 802.3z
• Single 3.3V power supply
• Low power dissipation
• Metal enclosure provides lower EMI
Specification
| Compatible OEM Part Number | ONS-SI-155-L2 | Optcore Part Number | OSP155-5580DTR-CSC |
| Form Factor | SFP | Data Rate | 155Mb/s |
| Wavelength | 1550 nm | Fiber Type | SMF |
| Max Distance | 80 km | Optical Components | FP/PIN |
| Transmitter Power | -5 ~ 0 dBm | Extinction ratio | > 10 dB |
| Receiver Sensitivity | < -32 dBm | Receiver Overload | > -3 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: -40°C to 85°C Storage: -40°C to 85°C |
Weight | 0.03 kg |
| Application | 100Base Fast Ethernet, SDH OC-3
SONET STM-1, FTTx |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
Download
Note: All trademarks, products and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is not certified or endorsed by Cisco.
