Unmanaged 1G SFP to 1G SFP Fiber Media Converter
US$ 27.00 (Excl. VAT)
High-performance Standalone 1G Fiber to Fiber Media Converter, Choosing the 1G SFP transceiver of your choice.
Model:
1x RJ45 to 1x 10G SFP+ 1x RJ45 to 1x SFP 4x RJ45 to 1x SFP 4x RJ45 to 2x SFP 1x RJ45 to 1x SC/ST/FC | 0.5km 1x RJ45 to 1x SC/ST/FC | 20km 1x RJ45 to 1x SC/ST/FC | WDM 20km
Category:
100M Media Converter 1G Media Converter 10G Media Converter PoE Media Converter Media Converter Chassis
Unmanaged 1GBase-X Fiber SFP to 1GBase-X Fiber SFP OEO Media Converter (2x Open 1G SFP Port)
The MC-1G-2SFP are protocol-transparent unmanaged fiber-to-fiber media converters/transponders with data speeds ranging from 155Mbps to 1.25Gbps. It supports the flexible transmission of many network protocols and cabling media types. The Fiber-to-fiber media converters help to convert multimode fiber to single-mode fiber and dual fiber to single-fiber to offer seamless integration of different fiber types. It increases network distance by converting wavelengths (1310 to 1550), increasing optical power, and supporting the “3Rs” of Retime, Regenerate, and Reshape.
The fiber-to-fiber media converter has two available SFP slots. The SFP slot is compatible with multimode and single-mode fiber and CWDM/DWDM wavelengths. It is a plug-and-play media converter that requires no manual configuration. Connect the fiber wires to the proper interface to complete the installation.
Features
• Cost-effective migration from Singlemode fiber to multimode fiber, dual fiber to single fiber, wavelength conversion
• Support Jumbo Frame
• Transparent Transport and very low delay
• Function as fiber repeater to support 3R (Re-amplifying, Re-shaping, Re-timing) optical signal regeneration
• Easy-to-view LED indicators to provide status to monitor network activity easily
• ROHS-compliant and Lead-Free
Specification
| Product Series | Fiber to Fiber Media Converter | Standards and Protocols | 1G Ethernet, SONET/SDH |
| Ports | 2 x 1G SFP port | Network Media | 1GBase-X: Multimode or Singlemode Fiber (max 80km, depends on the SFP module) |
| Flow control | Full Duplex: IEEE802.3x Half Duplex: back pressure |
LED indicator | Power, SPD, LOS1, LOL2, LOS2, LOL2 |
| Jumbo Frame | 9.6K | Enclosure | Compact-sized metal case |
| Wavelength | Depends on SFP Transceiver | Fiber Type | Multimode or Singlemode Fiber |
| Transmitter Power | Depends on SFP Transceiver | Receiver Sensitivity | Depends on SFP Transceiver |
| Power Supply | External Power Adapter Input: AC 100~240V 50/60Hz Output: DC 12V 1.6A |
Power Consumption | 5W |
| Dimensions (WxDxH) | 26×95×110mm | Gross Weight | 0.5 kg |
| Environment | Operating: 0°C to 50°C, 10~90% RH Storage: -40°C to 70°C, 5~90% RH |
Compliance | FDA IEC/EN 60825-1 ROHS, CE |
Ordering Information
| Optcore Part Number | Description |
| MC-1G-2SFP | 1G SFP to 1G SFP Fiber Media Converter (Without SFP transceiver) |
The MC-1G-2SFP supports the below 1GBASE-X SFP transceivers. Click the P/N to learn more detailed information.
Figure 1: EU Plug
Figure 2: US Plug
Figure 3: UK Plug
Power Adapter: To order the corresponding country-specific power supply, add the extension from the list below to the end of the model.
For example: MC-10G-SFP-EU, -EU = Country Code (EU = Europe, US = North America, UK = United Kingdom, SA = South Africa, CN = China)
