Cisco GLC-FE-100BX-D Compatible 100BASE-BX10-D SFP 1550nm-TX/1310nm-RX 10km Transceiver
US$ 7.90 (Excl. VAT)
Good quality Cisco GLC-FE-100BX-D compatible 100BASE-BX10-D SFP Transceiver (SMF, 1550nm-TX/1310nm-RX, 10km, LC, DDM).
Cisco GLC-FE-100BX-D Compatible 100BASE-BX10-D SFP Transceiver (BiDi, 1550nm-TX/1310nm-RX, 10km, LC, DDM)
Optcore’s OPB155-5320DCR-CSC is a high performance and cost effective small form factor pluggable (SFP) Bi-directional transceiver for 100BASE-BX Fast Ethernet application. It is fully comply with the SFP Multi-Sourcing Agreement (MSA) and can be used on the MSA compliant networking equipment.
The 100BASE-BX SFP transceiver is tested to be compatible with Cisco networking equipment including Ethernet Switches, Ethernet Routers, Network Interface Cards (NICs) and Ethernet Media Converters. The OPB155-5320DCR-CSC is an ideal equivalent to Cisco GLC-FE-100BX-D 100BASE-BX10-D SFP Transceiver but with a much lower price, which provides a reliable compatible SFP transceiver solution for ICT system integrator, distributors and end-users in network infrastructure and fiber cabling.
The 100BASE-BX SFP optics provide 10km high-speed data links using a single strand of fiber, which can upgrade transmission capacity very convenient without installing new fibers. The SFP transceiver module is a Class 1 laser product that complies with FDA/CDRH and IEC-60825 standards.
Features
• Support Up to 155Mbps data links
• Up to 10km on single 9/125µm SMF
• Compliant with SFP MSA standard
• Compliant with IEEE 802.3z
• Hot-pluggable SFP footprint
• Single 3.3V power supply
• Simplex LC connector
• 1550nm FP laser transmitter/1310nm InGaAs PIN receiver
• Low power dissipation
• The metal enclosure provides lower EMI
• ROHS compliant and Lead-Free
Specification
| Compatible OEM Part Number | GLC-FE-100BX-D | Optcore Part Number | OPB155-5320DCR-CSC |
| Form Factor | BiDi SFP | Data Rate | 155Mb/s |
| Wavelength | 1550nm-TX/1310nm-RX | Fiber Type | SMF |
| Max Distance | 10 km | Optical Components | FP/PIN |
| Transmitter Power | -13 ~ -8 dBm | Extinction ratio | > 10 dB |
| Receiver Sensitivity | < -30 dBm | Receiver Overload | > -3 dBm |
| Connector | LC Simplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: 0°C to 70°C
Storage: -40°C to 85°C |
Weight | 0.03 kg |
| Application | 100Base Fast Ethernet, SDH OC-3
SONET STM-1, FTTx |
Compliance | IEC/EN 61000-4-2,IEC-60825
FDA 21CFR 1040.10 and 1040.11 RoHS |
Compatibility
• 1900 Series Integrated Services Router - EHWIC-1GE-SFP-CU
• 1921 Series Router EHWC-1GE-SFP-CU
• 1941 Series Router HWC-1GE-SFP
• 2900 Series Integrated Services Router - Cisco 2921
• 2900 Series Integrated Services Router - Cisco 2951
• 2900 Series Integrated Services Router - HWIC-1GE-SFP
• 2900 Series Integrated Services Router - SM-D-ES2-48
• 2900 Series Integrated Services Router - SM-D-ES3-48-P
• 2900 Series Integrated Services Router - SM-D-ES3G-48-P
• 3900 Series Integrated Services Router - Cisco 3925
• 3900 Series Integrated Services Router - Cisco 3925E
• 3900 Series Integrated Services Router - Cisco 3945
• 3900 Series Integrated Services Router - Cisco 3945E
• 3900 Series Integrated Services Router - SM-D-ES2-48
• 3900 Series Integrated Services Router - SM-D-ES3-48-P
• 3900 Series Integrated Services Router - SM-D-ES3G-48-P
• 7600 Series Router - WS-X6148-FE-SFP
• 892F Series Wireless Integrated Services Router - CISCO892F-K9
• 892F Series Wireless Integrated Services Router - CISCO892FW-K9
• ASR 1000 Series Aggregation Services Router - ASR1002 - SPA-10X1GE-V2
• ASR 1000 Series Aggregation Services Router - ASR1002 - SPA-2X1GE-V2
• ASR 1000 Series Aggregation Services Router - ASR1002 - SPA-5X1GE-V2
• ASR 1000 Series Aggregation Services Router - ASR1002 - SPA-8X1GE-V2
• ASR 1000 Series Aggregation Services Router - ASR1002-X - SPA-10X1GE-V2
• ASR 9000 Series Aggregation Services Router - A9K-2T20GE
• ASR 9000 Series Aggregation Services Router - A9K-40GE-B
• ASR 9000 Series Aggregation Services Router - A9K-40GE-E
• Catalyst 2960 Series - WS-C2960-24PC-L
• Catalyst 2960 Series - WS-C2960-24TC-L
• Catalyst 2960 Series - WS-C2960-24TC-S
• Catalyst 2960 Series - WS-C2960-48PST-L
• Catalyst 2960 Series - WS-C2960-48TC-L
• Catalyst 2960 Series - WS-C2960-48TC-S
• Catalyst 2960 Series - WS-C2960-8TC-L
• Catalyst 2960 Series - WS-C2960-8TC-S
• Catalyst 2960 Series - WS-C2960G-24TC-L
• Catalyst 2960 Series - WS-C2960G-48TC-L
• Catalyst 2960 Series - WS-C2960G-8TC-L
• Catalyst 2960+ Series - WS-C2960+24TC-L
• Catalyst 2960+ Series - WS-C2960+24TC-S
• Catalyst 2960+ Series - WS-C2960+48PST-L
• Catalyst 2960-C Series - WS-C2960C-12PC-L
• Catalyst 2960-C Series - WS-C2960C-8PC-L
• Catalyst 2960-C Series - WS-C2960C-8TC-S
• Catalyst 2960-C Series - WS-C2960CG-8TC-L
• Catalyst 2960-S Series - WS-C2960S-24PS-L
• Catalyst 2960-S Series - WS-C2960S-24TS-L
• Catalyst 2960-S Series - WS-C2960S-24TS-S
• Catalyst 2960-S Series - WS-C2960S-48FPS-L
• Catalyst 2960-S Series - WS-C2960S-48LPS-L
• Catalyst 2960-S Series - WS-C2960S-48TS-L
• Catalyst 2960-S Series - WS-C2960S-48TS-S
• Catalyst 2960-X Series - WS-C2960X-18TS-LL
• Catalyst 2970 Series - WS-C2970G-24TS-E
• Catalyst 3560 Series - WS-C3560-24PS
• Catalyst 3560 Series - WS-C3560-24TS
• Catalyst 3560 Series - WS-C3560-48PS
• Catalyst 3560 Series - WS-C3560-48TS
• Catalyst 3560 Series - WS-C3560G-24PS
• Catalyst 3560 Series - WS-C3560G-24TS
• Catalyst 3560 Series - WS-C3560G-48PS
• Catalyst 3560 Series - WS-C3560G-48TS
• Catalyst 3560 Series - WS-C3560V2-24PS
• Catalyst 3560 Series - WS-C3560V2-24TS
• Catalyst 3560 Series - WS-C3560V2-48PS
• Catalyst 3560 Series - WS-C3560V2-48TS
• Catalyst 3560-E Series - WS-C3560E-12D
• Catalyst 3560-E Series - WS-C3560E-12SD
• Catalyst 3560-E Series - WS-C3560E-24PD
• Catalyst 3560-E Series - WS-C3560E-24TD
• Catalyst 3560-E Series - WS-C3560E-48PD
• Catalyst 3560-E Series - WS-C3560E-48PDF
• Catalyst 3560-E Series - WS-C3560E-48TD
• Catalyst 3560-X Series - WS-C3560X-24P
• Catalyst 3560-X Series - WS-C3560X-24T
• Catalyst 3560-X Series - WS-C3560X-48P
• Catalyst 3560-X Series - WS-C3560X-48PF
• Catalyst 3560-X Series - WS-C3560X-48T
• Catalyst 3750 Metro Series - ME-C3750-24TE-MA
• Catalyst 3750 Metro Series - ME-C3750-24TE-MD
• Catalyst 3750 Series - WS-C3750-24FS-S
• Catalyst 3750 Series - WS-C3750-24PS
• Catalyst 3750 Series - WS-C3750-24TS
• Catalyst 3750 Series - WS-C3750-48PS
• Catalyst 3750 Series - WS-C3750-48TS
• Catalyst 3750 Series - WS-C3750G-12S
• Catalyst 3750 Series - WS-C3750G-24PS
• Catalyst 3750 Series - WS-C3750G-24TS
• Catalyst 3750 Series - WS-C3750G-24TS-E1U
• Catalyst 3750 Series - WS-C3750G-24TS-S1U
• Catalyst 3750 Series - WS-C3750G-48PS
• Catalyst 3750 Series - WS-C3750G-48TS
• Catalyst 3750 Series - WS-C3750G-48TSS-RF
• Catalyst 3750 Series - WS-C3750V2-24PS
• Catalyst 3750 Series - WS-C3750V2-24TS
• Catalyst 3750 Series - WS-C3750V2-48PS
• Catalyst 3750 Series - WS-C3750V2-48TS
• Catalyst 3750-E Series - WS-C3750E-24PD
• Catalyst 3750-E Series - WS-C3750E-24TD
• Catalyst 3750-E Series - WS-C3750E-48PD
• Catalyst 3750-E Series - WS-C3750E-48PDF
• Catalyst 3750-E Series - WS-C3750E-48TD
• Catalyst 3750-X Series - WS-C3750X-24P
• Catalyst 3750-X Series - WS-C3750X-24P-L
• Catalyst 3750-X Series - WS-C3750X-24P-S
• Catalyst 3750-X Series - WS-C3750X-24T
• Catalyst 3750-X Series - WS-C3750X-24T-L
• Catalyst 3750-X Series - WS-C3750X-24T-S
• Catalyst 3750-X Series - WS-C3750X-48P
• Catalyst 3750-X Series - WS-C3750X-48PF
• Catalyst 3750-X Series - WS-C3750X-48PF-L
• Catalyst 3750-X Series - WS-C3750X-48PF-S
• Catalyst 3750-X Series - WS-C3750X-48P-L
• Catalyst 3750-X Series - WS-C3750X-48P-S
• Catalyst 3750-X Series - WS-C3750X-48T
• Catalyst 3750-X Series - WS-C3750X-48T-S
• Catalyst 3850 Series - 3850-24F-E
• Catalyst 3850 Series - 3850-24P-E
• Catalyst 3850 Series - 3850-24P-L
• Catalyst 3850 Series - 3850-24P-S
• Catalyst 3850 Series - 3850-24T-E
• Catalyst 3850 Series - 3850-24T-L
• Catalyst 3850 Series - 3850-24T-S
• Catalyst 3850 Series - 3850-48F-L
• Catalyst 3850 Series - 3850-48F-S
• Catalyst 3850 Series - 3850-48P-E
• Catalyst 3850 Series - 3850-48P-L
• Catalyst 3850 Series - 3850-48P-S
• Catalyst 3850 Series - 3850-48T-E
• Catalyst 3850 Series - 3850-48T-L
• Catalyst 3850 Series - 3850-48T-S
• Catalyst 4948-E Series - WS-X4993
• Catalyst C2960-X Series WS-C2960X-48TS-L
• Catalyst C2960-XR Series WS-C2960XR-24PD-I
• Catalyst C2960-XR Series WS-C2960XR-24PS-I
• Catalyst C2960-XR Series WS-C2960XR-24TD-I
• Catalyst C2960-XR Series WS-C2960XR-24TS-I
• Catalyst C2960-XR Series WS-C2960XR-48FPD-I
• Catalyst C2960-XR Series WS-C2960XR-48FPS-I
• Catalyst C2960-XR Series WS-C2960XR-48LPD-I
• Catalyst C2960-XR Series WS-C2960XR-48TD-I
• Catalyst C2960-XR Series WS-C2960XR-48TS-I
• Catalyst Express 500 - WS-CE500-12TC
• Catalyst Express 500 - WS-CE500-24LC
• Catalyst Express 500 - WS-CE500-24PC
• Catalyst Express 500 - WS-CE500G-12TC
• Catalyst Express 520 - WS-CE520-24LC-K9
• Catalyst Express 520 - WS-CE520-24PC-K9
• Catalyst Express 520 - WS-CE520-8PC-K9
• Catalyst Express 520 - WS-CE520G-24TC-K9
• ME 3400 - ME-3400-24CS-A
• ME 3400 - ME-3400-24FS-A
• ME 3400 - ME-3400-24TS-A
• ME 3400 - ME-3400-24TS-D
• ME 3400 - ME-3400G-12CS-A
• ME 3400 - ME-3400G-12CS-D
• ME 3400 - ME-3400G-2CS-A
Download
Note: All trademarks, products and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is not certified or endorsed by Cisco.
| Weight | 0.03 kg |
|---|
