Finisar® FTLF8519P2BNL Compatible 1000BASE-SX & 2GFC SW Extended SFP Transceiver
US$ 17.00 (Excl. VAT)
2G Fibre Channel SFP module (MMF, 850nm, 300m, LC, E-Temp, DOM) for replacing Finisar® FTLF8519P2BNL.
Finisar® FTLF8519P2BNL Compatible 2GFC SW Extended SFP Module (MMF, 850nm, 300m, LC, -20°C ~ 85°C, DOM)
This 2G fiber channel extended temperature SFP module is designed for industrial networking equipment and is equivalent to Finisar® genuine part number FTLF8519P2BNL. It is programmed and tested at the factory, to ensure works same as Finisar® FTLF8519P2BNL. This hot-swappable transceiver provides maximum 300m transmission distance over multimode fiber (MMF) cabling at a wavelength of 850nm. It complies with Gigabit Ethernet as specified in IEEE Std 802.3 and 1x and 2x Fibre Channel.
Features
• Functionally identical to Finisar® FTLF8519P2BNL
• Support up to 2.125Gb/s data links
• Compliant with IEEE 802.3z
• Single 3.3V power supply
• LC Duplex connector
• Built-in digital diagnostic functions
• Extended operating temperature range: -20°C to 85°C
• ROHS compliant and Lead-Free
Specification
| Compatible OEM Part Number | FTLF8519P2BNL | Optcore Part Number | OSP2125-8503DER-FNS |
| Form Factor | SFP | Data Rate | 2.125Gb/s |
| Wavelength | 850 nm | Fiber Type | MMF |
| Max Distance | 300 m | Optical Components | VCSEL/PIN |
| Transmitter Power | -10～-3 dBm | Extinction ratio | > 8.2 dB |
| Receiver Sensitivity | < -18 dBm | Receiver Overload | > -3 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: -20°C to 85°C Storage: -40°C to 85°C |
Weight | 0.03 kg |
| Application | 1G /2G Fibre Channel (1GFC, 2GFC) 1000BASE-SX Gigabit Ethernet |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
Compatibility
Download
Note: All trademarks, products and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is NOT certified or endorsed by Finisar®.
| Weight | 0.03 kg |
|---|
