Mellanox MAM1Q00A-QSA28 Compatible 100G QSFP28 to 25G SFP28 Adapter Converter
US$ 59.00 (Excl. VAT)
100G QSA Adapter Converter Module allows you to use an SFP28 transceiver in the QSFP28 port.
Mellanox MAM1Q00A-QSA28 Compatible 100G QSFP28 to 25G SFP28 Adapter Converter (QSA Adapter, Multimode/Singlemode/DAC/AOC)
Optcore QSFP28 to SFP28 Adapter Converter Module (QSA Adapter) offers a low-priced alternative replacement for Mellanox MAM1Q00A-QSA28 without sacrificing the quality of your fiber optic network connectivity. It provides a convenient, easy-to-use mechanical adapter to converter a 100G QSFP28 port into a 25G SFP28 port. It offers 25 Gigabit Ethernet connectivity for Quad Small Form-Factor Pluggable (QSFP28)-only platforms. The QSA adapter provides a cost-effective converter module to connect a slower 25G SFP28 transceiver or cable to a 100G QSFP28 port. Plug and play, no configuration required; it allows customers to use any SFP28 module or cable to connect to a lower-speed port on the older equipment. This compatible QSFP28 to SFP28 Adapter Converter Module has been programmed and tested to work as the original Mellanox MAM1Q00A-QSA28 100G QSA adapter.
Features
• Cheap QSFP28 to SFP28 adapter module compatible with your Mellanox MAM1Q00A-QSA28 100G QSA Adapter Converter Module
• Trouble-free installation and network bring-up
• Low insertion loss & Low crosstalk
• Compliant with industry standards: QSFP28 MSA SFF-8665 / SFP28 MSA SFF-8432
• Allow you to use SFP28 in the QSFP28 port of your device
• Plug and play, no configuration needed
• Precision process control for minimization of pair-to-pair skew
• Operating temperature range:0~70ºC
• SFP+ transceivers are not included and sold separately
• RoHS compliant and lead-free
Specification
| OEM Part Number | MAM1Q00A-QSA28 | Optcore Part Number | CVT-QSFP28-SFP28-MEL |
| Form Factor | QSFP28 to SFP28 | Data Rate | 100 Gb/s |
| Wavelength | N/A | Fiber Type | Depends on SFP28 Transceiver |
| Max Distance | Depends on SFP28 Transceiver | Optical Components | N/A |
| Transmitter Power | N/A | Extinction ratio | N/A |
| Receiver Sensitivity | N/A | Receiver Overload | N/A |
| Connector | SFP28 | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C |
Weight | 0.09 kg |
| Application | ● Low EMI radiation Switches, servers and routers ● Telecommunication and wireless infrastructure ● Test and measurement equipment ● Networked storage systems ● Data Center networks ● Storage area networks |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS,SFF-8665,IEEE802.3ba |
Download
Note: All trademarks, products and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is NOT certified or endorsed by Mellanox.
| Weight | 0.07 kg |
|---|
