Brocade 25G-SFP28-SR Compatible 25G SFP28 SR 850nm 100m Transceiver
US$ 16.90 (Excl. VAT)
25G SFP28 SR Transceiver for use with Brocade 25GbE switches and routers.
25G-SFP28-SR Compatible 25G SFP28 SR Transceiver (MMF, 850nm, 100m, LC, DDM)
This 25G-SFP28-SR Compatible 25G SFP28 SR transceiver is designed for use with Brocade 25 Gigabit Ethernet connectivity in data center and high-performance computing networks applications. It is programmed and tested to perform identical to original Brocade 25G-SFP28-SR 25GBASE-SR SFP28 transceiver and provide a cost-effective replacement. It can be used in 25 GE SFP28 ports of Brocade Fiber Switches, Routers, Line card, and so on. The SFP28 SR module support max links of 70m over OM3 or 100m over OM4 multi-mode fiber.
Features
• Functionally similar to Brocade 25G-SFP28-SR
• Hot-pluggable SFP28 form factor
• Support for 25Gb/s data rate
• 850nm VCSEL transmitter, PIN photo-detector
• Distance up to 100m on OM4 Multi-mode fiber
• LC Duplex connector
• Built-in digital diagnostic functions
• Single 3.3V power supply
Specification
| Compatible OEM Part Number | 25G-SFP28-SR | Optcore Part Number | SFP28-25G-SR-BRO |
| Form Factor | SFP28 | Data Rate | 25 Gb/s |
| Wavelength | 850 nm | Fiber Type | MMF |
| Max Distance | 70m on OM3, 100m on OM4 | Optical Components | VCSEL/PIN |
| Transmitter Power | -8.4 ~ 2.4 dBm | Extinction ratio | > 2 dB |
| Receiver Sensitivity | < -10 dBm | Receiver Overload | > 0.5 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C |
Weight | 0.03 kg |
| Application | 25GBASE-SR Ethernet | Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
Download
Note: All trademarks, products and company names mentioned are the property of their respective owners and are used for comparative purposes only. This product is NOT certified or endorsed by Brocade.
| Weight | 0.03 kg |
|---|
